Good feeling and more actuators and more terminals are applied
SPECIFICATION
Mechanical life:1,000,000 cycles min Contact Rating:10.1Amps@125/250 VAC; CUL, UL 6,000 cycles Insulation Resistance:>100MΩ DC500V Withstand Voltage:AC1,000V 1 minute Contact Resistance:<50mΩ Operating Temper.:-25°C to 75°C; Operating Force:See Chart Hand Soldering.:Use a soldering iron of 30 watts,controlled at 380℃ approximately 3 seconds while applying solder。
